MD168053 MD094740 4D56 Mitsubishi Turbocharger 49177-01500 4917701500
Description of Mitsubishi Turbocharger
The advantage of an electrically assisted turbocharger is that the electric motor can not only be used to drive the turbocharger shaft, but it can also be used to brake it: the electric motor then becomes a generator and creates electricity. In situations where there is too much power available for the turbocharger shaft, the electrically assisted turbocharger is able to generate useful energy and can thus lower the fuel consumption and emissions of a vehicle. In addition, the electric motor is integrated into the turbocharger, so it is a compact and easy-to-install solution.
Specification of Mitsubishi Turbocharger
| Part Number |
49177-01500,4917701500, 49177-01501, 49177-01510, 49177-01511 |
| OE number |
MD168053, MD094740 |
| Turbo model |
TDO4 |
| Engine |
4D56 |
| Description | for Mitsubishi with 4D56 Engine |
| Turbine housing | High silicon molybdenum nodular iron .heat-resistant950° |
| Compressor housing | ZL101 Cast aluminium |
| Compress wheel | ZL201 or C355 cast aluminum |
| Turbine shaft & wheel | 42CrMo and k418.heat-resistant>950° |
| Journal bearing and thrust bearing | CW713R copper aolly |
| Bearing housing | High silicon molybdenum nodular iron. |
| Size | standard |
More details:
Information about other products:
| TA3134 | ME088725 ME088488 | 49185-01010 466129-5003 | 6D31T |
| TC05-10A 3孔 | MD017658 | 49168-01202 49178-00500 | 4D31 4D55T 4D56T 2.3L |
| TD02 | MD613083 MR312649 | 49130-01610 49130-01600 | 4A30 1.6L |
| TD04-10T-4(1) | MR355223 MD194843 MD194842 | 49177-01504 49177-01502 | 4D56-water |
| TD04-10T-4 | MR355223 MR355222 | 49177-01502 49177-01504 | 4D56-oil 2.5L |
| TD04-10T/4(2) | MD168053 | 49177-01510 49177-01511 | 4D56-oil 2.5L |
| TD04-09B/4 | MD094740 MD168053 | 49177-01500 01501 | 4D56-oil 2.5L |
| TD04-09B/4 (3) TD04-10T/4 | MR355220 28200-4A210 | 49177-01515 49177-01513 | 4D56-water 2.5L |
| TD04 | MD194841 | 49177-01512 | 4D56-water |
| TD04-9G | MR355598 MD197914 | 49177-02701 02700 | 4D68 |
| TD04 5孔 油 | MD155984 | 49177-02510 | 4D56Q 2.5L |
| TD04-11B | MD187208 MD170563 | 49177-02500 02501 | 4D56Q 4D56TD 2.5L |
| TF035 水冷 浅口 | MD194844 | 49177-02502 49177-08250机芯号 | 4D56Q |
| TD05-14G /TD05-3 /TD05H | ME014881 | 49178-02385 | 4D34T4 |
| TD05H-12B | ME013134 | 49178-02110 | 4D34T1 |
| TD05H-14G-10 | ME212182 | 49S78-02345 02390 | 4D34-3AT |
| TD05 | ME224776 | 49178-02390 | 4D34T4 |
| TDO6-11A/8 | ME013714 | 49179-00210 | 4D31T 3.3L |
| TD06-4 | ME073623 | 49179-00260 | 6D15 4D31 6D31 4D34T |
| TD06-14A | ME013734 | 49179-00230 | 4D31T |
| TD06-17C | ME088256 | 49179-02110 | 6D31T |
| TE06-12M SK200-3 (TA31) | ME088725 | 49185-01010 | 6D31T |
| TE06H-16M | ME440895 | 49185-01031 01030 | 6D34T |
| TD07-22A-17.0(普通) | ME050579 ME047102 | 49175-00418 | 6D16WT, 6D16 (6D15) |
| TD07S(TD07-2) | ME033810 | 49187-00200 | (1)6D-14 (2)6D16T2 |
| TD07S-25A /13 (TD07-9) | ME073935 ME073573 | 49187-00270 49187-01010 49187-00271 | 6D16T |
| TD07S | D38000680 | 49187-02500 | 6D16T |
| TD07S | D38000682 | 49187-02700 | D6114ZG2B/D6114ZG5B |
| TD07S | D38000681 | 49187-02710 | 6D16 D6114ZG1B |
| TD08 | ME351183 | 49188-02500 | 6D22 |
| TD08H-22B/28 | ME053939 | 49188-01261 | 6D22T, 6D22T3 |
| TD08H-22D(原机) | ME158162 ME150485 | 49188-01651 01281 | 6D22T,6D24T |
| TD08H-27VRC | 114400-3743 3742 | 49188-01811 01813 | 6WA1 6WF1-T |
| TD08H | 49188-04001 | TD08H-2 | |
| TD08H / diesel6121 | 38AB004 49188-04230 | 49188-04210T 49188-04073 | D6121 diesel3306 |
| TD08 LH | ME097476 | 49174-00592 | 8DC91T |
| TD08 RH | ME091427 | 49174-00593 | 8DC91T |
| TD08 | ME053936 | 49174-01142 | 6D22 |
| TD08H-2 | 6138-000-310 | ||
| TD13M-48QRO | 76.89.071, 7689071 | 49182-05210 | SFGLD560 V16 |
| TE06H-16M | ME088840 | 49185-01020 | 6D34T |
| TE06H TD06H | 111.2DZ-031G-A | 49185-04810 | NQ190N |
| TF035HM-12T/4 | MR212759 | 49135-02110 02100 | 4D56TD 2.5L |
| TF035HL2-12GK VNT | MR968080 | 49135-02652 | 4D56U 2.5L |
| TF035, TF035HL-14GK2 | 49135-02910 | 49135-02920 | 4M41 water |
| TF035 TD04-12T | ME201635 | 49377-03033 03031 03030 | 4M40 2.8L |
| TF035 TDO4-12T/4 | ME201258 | 49377-03041 | 4M40 2.8L oil |
| TF035HM-12T (4) | ME201677 ME202012 | 49135-03101 03100 03311 | 4M40-water 2.8L |
| TF035HL14GK | ME203949 | 49135-03410 | 4M41 water 3.2L |
| TF035HL-14GK | ME203949 | 49135-03411 | 4M41 oil 3.2L |
| TF035 | ME203933 | 49135-03500 03501 | 4M40 2.8L |
We can safely and confidently say that the technology and quality of our turbocharger are first class ,which is the perfect replacement for the original turbocharger.
Our Services
1) Pre-sale service:
Offer you reasonable price of the products you need and reply related questions.
2) Medium-sales service:
Every turbocharger element you need will be tested strictly before delivery .
3) After-sales service:
Technical advisory for any time.
4) More Service:
1. We can delivery the products by sea ,by air ,or the express,such as DHL ,TNT ,UPS ,SF,EMS and so on .
2. Our customer can pay for by TT, Western Union ,or others.
FAQ
| 1. | Q: How long is your delivery time? A: Generally it is 1-2 days if the goods are in stock,or it is 7-15 days if the goods are not in stock, it is according to the model and quantity of the goods you provide |
| 2. |
Q:How can I do if there is something wrong with the items? A:we have confidence in the quality of our products ,if you really found something wrong ,please contact us.We have a special after-sales department to solve these problems until you are satisfied |
| 3. | Q: Do you provide samples ? is it free or not ? A: Yes, we could offer the sample but not free. |
| 4. | Q: Where are your overseas markets? A: Our products are well selling in Southeast Asia, the Middle East, Africa,South America, Europe... |
| 5. |
Q:What are your terms of payment? A:50% desposit in advance, 50% balance before delivery,We accept L/C, T/T, Paypal, Western Union,Trade Assurance |
Our products are sold all over the world, you can rest assured.
